FIBRE OPTIC CABLES > INDOOR > UNI-TUBE

INTERCONNECT CABLES

Applications

Communication racks and wiring closets, walls, ceilings, floor ducts, etc
In the final connection to terminal devices such as workstation and computer terminals for high speed voice, video, data, and FTTx applications
Short run office & computer room cabling
Patch cords, Pigtails & Jumpers

Typical Cross Section of Simplex

Cable Construction Details - Simplex

A single optical fibre is tight buffered and surrounded by aramid yarn strength member and jacketed with riser or plenum or LSZH grade jacketing to 2.0/3.0 mm diameter.
