FIBRE OPTIC CABLES > MICROMODULE > UNI‐TUBE

1F - 24F Single Sheath Micro Module
Optical Fibre Cable

Applications

  • The universal design is suited for use in most network arenas, including backbone, access and distribution.
  • Quick fibre preparation ready for installation
  • Installation Outdoor to Indoor
Ipsum

Typical Cross section of 12 Fibre

Cable Construction Details

  • The micro‑module unit consist up‑to 24 fibres, an easily strippable and flexible.
  • High Modulus, Aramid yarn as peripheral strength member
  • LSZH Outer sheath

Technical Characteristics

FIBRE COUNT DIAMETER (mm) Nominal WEIGHT (Kg./Km) Nominal TENSILE STRENGTH (N) BENDING RADIUS (mm) TEMPERATURE RANGE
(IEC 60794-1-2-F1)
Installation Operation Installation Operation Installation Operation
1F 4.0 15 300 150 10D 20D -5°C to +50°C -10°C to +60°C
2F 4.0 15 300 150 10D 20D -5°C to +50°C -10°C to +60°C
4F 4.0 15 300 150 10D 20D -5°C to +50°C -10°C to +60°C
6F 4.5 18 300 150 10D 20D -5°C to +50°C -10°C to +60°C
8F 4.5 18 300 150 10D 20D -5°C to +50°C -10°C to +60°C
12F 4.8 22 300 150 10D 20D -5°C to +50°C -10°C to +60°C
24F 5.5 26 300 150 10D 20D -5°C to +50°C -10°C to +60°C

Fiber Colour Coding

Blue Orange Green Brown Grey White Red Black Yellow Violet Pink Aqua

Micro Module Colour Coding

Blue
*For Fibre Count 12F We provide the above colour code

Special Features

  • Reduced diameter micro modules
  • Flexible Micro modules are easily removed without the need for tools
  • Reduce installation time and costs
  • Small cable diameter & light weight
  • Requires no grounding or bonding due to all‑dielectric construction
  • All dielectric construction.

Drum Length

  • 2000/ 4000 meters ± 5%

Mechanical Characteristics

Impact Resistance (Nm) [IEC 60794-1-2-E4] Height 0.3 meters,
Weight = 0.1 Kg, 1 Nos
Crush Resistance (N) [IEC 60794-1-2-E3A] 500 N [100 X 100 mm] for
10 minutes, 3 times 500 mm apart
Torsion Resistance [IEC 60794-1-2-E7] 10 Cycle [± 180°] 20 N Weight,
Length under Test‑1 meters
Water Penetration [IEC 60794-1-22-F5 B] 1 Meter Water Head,
3 Meters Cable Sample, 24 Hours
